Home / Products / MULTI-POSITION SPOOL PAY-OFFS & TAKE-UPS / SAB/AAB SERIES

SAB/AAB SERIES

Wire & Rope
MULTI-POSITION SPOOL PAY-OFFS & TAKE-UPS
Description

The SAB / AAB series plays a pivotal role in both pay-off and take-up operations, offering their versatility across a wide spectrum of wire types. This includes annealed and galvanized low carbon wire, patented and phosphated or galvanized high carbon wire. Furthermore, they are well-suited for hard-drawn and galvanized high carbon wire (ACSR), patented and brass-coated high carbon wire (Steel Cord), hard-drawn and bronze-coated high carbon wire (Bead Wire), as well as aluminum-clad high carbon wire.

The multi-position spool pay-offs & take-ups are designed for low, medium, high carbon or stainless steel wire for thermal treatment and/or coating and/or cleaning operations.

The use of accumulation capstan pay-offs and take-ups is crucial in situations where a continuous, uninterrupted process is necessary during spool change operations.

Key Benefits
Capstan available from Ø 350 to 560 mm
Wire range Ø from 0.6 to 5.5 mm
Double head accumulation block solution
Max linear speed depending upon takeup model
Nonstop operations during spool change
Fine regulation of the wire back pull
Capstan available from Ø 300 to 710 mm on take-ups and 350 to 560 mm on pay-offs
Wire range Ø from 0.6 to 7.0 mm on take-ups and from 0.6 to 5.5 mm on pay-offs

Support form our Help Desk

Worldwide Distribution

Possibilities of upgrades
